Oasis® 2800 Patio Shades

Insolroll Oasis 2800 Patio Shade at sunset

Solar Screen Patio Shades for Large Patios and Exterior Window Applications



Oasis 2800 Patio shades from Insolroll open deck installation

Everyone enjoys spending time outdoors with family and friends. Oasis 2800 Patio Shades enhance the use of outdoor living spaces by filtering the heat and glare of the sun while maintaining an airy open feeling and view to the exterior. Our roll-up solar screen shades dramatically extend the hours of quality time you can use your patio or deck by making them more comfortable in the morning or afternoon hours when the sun angle is low.

  • Custom sizes to 19′ wide
  • Motorized with Somfy or Driven by Lutron™ Systems
  • Manual hand crank operation available
  • Choice of side track or cable guide fabric stabilization system
  • Welded fabric edges for durability

Shades can be retrofitted to existing covered patios, screen porches, gazebos, and open trellis structures.  Shades can also be designed into new backyard construction projects.

Protect your deck, patio or pergola from glare, heat, golf balls, and view by neighbors

country club patio shades golf ball protection Oasis 2800

Oasis 2800 Deck and Patio Shades were invented in 1986 for Patio Sun Protection.  Our shades will dramatically reduce sun glare and keep you cool to enjoy the great outdoors. Shades provide protection from errant golf balls and a level of privacy from nearby neighbors. Making your patio area safe and private is what our Oasis® brand is all about. Dense solar screen fabric weaves provide excellent daytime privacy. Light colors screens provide the best privacy.



Oasis Patio Shades fit any design style

Solar screen patio shades for large and small openings

Oasis 2800 Patio Shades on High Rise balconyOasis Patio Shades are ideal for multi family applicationsOasis® 2800 Solar Screen Shades are engineered to accommodate large patio openings up to 19′ wide by 14′ tall.  We can accommodate small openings as narrow as 31 3/8″ with a motorized shade.  All Oasis 2800 shades are custom-made with a choice of side track or cable guide systems to provide greater stability in a light breeze.  These solar screen patio shades include a fully enclosed 5″ x 5 1/2″ extruded aluminum headbox for greater product protection when retracted.  Shades are available with hand crank or motorized operation.

Oasis 2800 Patio Sun Shade Solar Screen Fabric Collection

Sun control fabrics for outdoor living

Solar screen fabrics provide great glare control characteristics on a patio.

  • Selecting dense solar fabrics (1%, 3%, 0r 5% openness) can resolve harsh glare situations from the setting sun.
  • Dark colors provide the best view-through and glare control characteristics.
  • Light fabrics provide better daytime privacy.
  • Solar screen fabrics with greater openness (8%-10%) provide better view through.

Our original patio shade design is made even more versatile by our broad fabric selection. Choose from a wide array of colors, textures and styles to complement every patio design and color scheme. Beautiful design doesn’t have to stop at the patio door!

Download Technical Fabric Characteristics (PDF)

Aurora

Solar Screen Fabrics Insolroll® Solar Shades, Oasis® Patio Shades For Interior & Exterior use

Fire-rated (FR) Aurora solar screen fabric consists of vinyl-coated polyester yarns woven in a 2 x 2 basketweave configuration. This value-priced fabric provides excellent view-through visibility. 27% Polyester, 73% PVC solar fabric in 3% and 5% openness choices. Click to view larger swatches.

White/Bone
Bone
White/Grey
Grey/Bone
Charcoal/Bronze
Charcoal

Dusk Exterior Blackout

Blackout Fabrics Oasis® Patio Shades For Exterior use

Made of solution-dyed acrylic fiber with a PVC back coating, Dusk blackout/privacy fabric is completely waterproof and combines the elegance of an acryic canvas-look fabric with the waterproof performance of PVC on the out-facing surface. Offering complete privacy, dusk's PVC Back coating features Blockout finishing for thermal and visual comfort, as well as maximal protection from the sunlight.

Beige
Raw
White
Cadet Grey
Download Technical Fabric Characteristics (PDF)

Kona

Solar Screen Fabrics Oasis® Patio Shades For Exterior use

Vinyl-coated fiberglass solar screen fabric, Kona is woven in a basket weave configuration for excellent view-through.

White (Kona)
Bone (Kona)
Bone/Platinum
Bronze
Charcoal/Grey
Charcoal
Download Technical Fabric Characteristics (PDF)

Mesa

Solar Screen Fabrics Insolroll® Solar Shades, Oasis® Patio Shades For Interior & Exterior use

FR solar screen fabric, Mesa is woven in a 2 x 2 basketweave pattern, available in wide widths and 7 stylish colors. With a composition of 37% fiberglass and 63% vinyl on fiberglass, each color is available in 4 densities: 1%, 3%, 5%, and 10%. Click to view larger swatches.

Oyster
Beige/Pearl Grey
Charcoal
Pearl Grey
Beige
Charcoal/Alpaca
Charcoal/ Chestnut
Download Technical Fabric Characteristics (PDF)

Natural Weave

Solar Screen Fabrics Insolroll® Solar Shades, Oasis® Patio Shades For Interior & Exterior use

Fire-rated (FR) solar screen fabric woven with diverse textures and rich colors for a natural shade appearance with superior durability, minimal maintenance and excellent outward view-through. In 5-10% openness, composition varies for each fabric. PVC coated polyester with additional acrylic or olefin yarns. Click to view larger swatches.

Rattan Umber
Bark Tiger Oak
Bamboo Wheat
Tweed Oatmeal
Tweed Buckeye
Download Technical Fabric Characteristics (PDF)

Natural Weave Linen

Solar Screen FAbrics Insolroll® Solar Shades, Oasis® Patio Shades For Interior & Exterior use

Our Natural Weave Linen collection features FR solar screen fabrics woven with a slubbed texture and varied colors for a sophisticated, linen-like appearance. Made of polyester and vinyl, the fabric's 3% openness provides excellent outward visibility. Click to view larger swatches.

Pearl
Cinnamon
Clay
Taupe
Cream
Burlap
Topaz
Fig
Download Technical Fabric Characteristics (PDF)

Palisade

Solar Screen Fabrics Oasis® Patio Shades For Exterior use

Woven from thick, 165 Tex core yarns, Palisade solar fabric has added strength and durability for extra-wide patio shade applications. Weather-resistant, this premium fabric features basket weave pattern for optimal view-through.

Charcoal/Charcoal
Charcoal/Cocoa
Download Technical Fabric Characteristics (PDF)

Season

Translucent Fabrics Oasis® Patio Shades For Exterior use

Exterior translucent fabric composed of high tenacity polyester with a PVC coating. 0% openness with no view-through, and a waterproof finish layer. Recyclable. Click to view larger swatches.

Cream
Dove
Sand
White
Download Technical Fabric Characteristics (PDF)

Shore

Translucent Fabrics Oasis® Patio Shades For Exterior use

High tensile- and tear-strength acrylic translucent fabric for privacy, sun protection and resistance to rain. Click to view larger swatches.

Linen Tweed
Raw
Charcoal Tweed
Cadet Grey
Download Technical Fabric Characteristics (PDF)

Tuff Screen®

Insect Screen Oasis® Patio Shades For Exterior use

Heavy-duty vinyl-coated insect screen designed to keep out mosquitoes and other insects. Three times stronger than regular insect screens, it is pet-resistant, tear-resistant and puncture-resistant. 45% openness; click to view larger swatch.

Black
Download Technical Fabric Characteristics (PDF)

Tuff Screen® No-See-Ums

Insect Screen Oasis® Patio Shades For Exterior use

Vinyl-coated polyester insect screen with very small apertures to keep out very small insects such as No-See-Ums, or biting midges. 48% openness; click to view larger swatch.

Black

Oasis® 2800 Patio Shade operation

large outdoor living space Insolroll Oasis 2800 patio shades

Insolroll offers 2 industry leading motorization systems for Oasis 2800 Patio Shade. The convenience of motorization offers on-demand shade with one-touch operation as well as control by scenes, scheduling, voice control, and mobile device control.

Somfy Radio Motors and Controls

Somfy has been the international leader in motorization for outdoor shading systems for nearly 50 years. Insolroll’s Quiet Radio Motor (IQM-ACR) is a 110 V AC motor utilizing a 6 N•m or 10 N•m Somfy motor depending upon shade size.

Additional Somfy Motor Options

  • IQM-AC: 110 V AC quiet bi-directional motor with 4-wire hardwire switch control
  • IQM-485-AC: 110 V AC power input and data cable connection to digital network. Ideal for large home automation and building control applications.

Somfy Motorized Shade Controls

  • Simple radio control with wireless wall switch or outdoor radio transmitter
  • Somfy MyLink app-based control allows control with mobile devices even when you’re away, and voice control

Somfy 1 channel wireless wall switch
Indoor wireless Radio Wall Switch (available with 1,2,3.4, or 5 channels)

Somfy patio radio transmitter
Outdoor radio transmitter (single-channel or 5-channel)

Somfy mylink device images
Somfy MyLink® wifi app-control for iOS, Android, voice control and integration devices

Lutron Electronic Drive Unit Systems



Our technical alliance with Lutron Electronics brings best-in-class motorized outdoor shading systems to the luxury home market. Lutron Roller 300 Electronic Drive Unit 35 V DC drive integrates seamlessly with Lutron Homeworks QS®, Radio RA2®, and Caséta® Controls.

Lutron dongle receiver for motorized shade from Insolroll
RF Dongle Radio Receiver

Lutron pico wireless remote transmitter
Pico® Wireless Remote Control Transmitter

Lutron pica tabletop pedestal for pica remote for motorized patio shade
Tabletop pedestal for Pico Remote


Lutron Control Options

  • Simple wireless switches and transmitters for standalone applications, RadioRA2® or Caséta wireless lighting control systems
  • Complete integration with Lutron HomeWorks®

Learn more about Oasis Shades Driven by Lutron

Exterior hand crank operation

Hand crank and gear operation of a patio shade is made easy by dual grips at the end of the handle. When not in use, the handle is removable. Manual crank operated shades are available up to 16′ wide and heights up to 10′.

Insolroll Patio Shade with crank operation photo and diagram

Oasis® 2800 Patio Shade Hardware

Roller Housing Options

All options available in 4 colors, for both side track or cable guide, and for ceiling or surface mount

5″ x 5 ½” Extruded Aluminum Head Box

Insolroll Oasis 2800 headbox diagram

Insolroll Oasis 2800 Headbox photo

  • 5-sided
  • Surface or ceiling mount
  • White, Bronze, Tan, and Black

5″ x 5 ½” Extruded Aluminum Pocket; exposed or recessed

Insolroll Oasis 2800 flap and hanger diagram

Insolroll Oasis 2800 flap & hanger photo

  • 3 ½” Access Flap mounts to front of extruded head box
  • Surface or ceiling mount
  • White, Bronze, Tan, and Black


Exposed Bracket for Exposed Roller Applications and Custom Pocket

Insolroll Oasis 2800 cable guide system diagram

Insolroll Oasis 2800 mounting bracket illustration

  • 3 ½” x 4 ⅓” x 3 ¼” heavy-duty aluminum bracket
  • Surface or ceiling mount
  • Silver only?

Built-in Options

Custom Site-built Pocket

Our exposed bracket is designed for built-in applications in new construction. The shade is installed in a pocket, or cavity, inside the ceiling. It comes down when needed and retracts away out of sight when not needed.
Insolroll Oasis 2800 pocket installation diagram

Insolroll Oasis 2800 built in pocket illustration

  • 6 ½” x 9″ cavity built-in above the ceiling
  • 3 ½” Aluminum Access Flap mounts to Aluminum Hanger inside from of pocket

Track Guide and Cable Guide Fabric Stabilization Systems

Fabric stabilization systems keep shade fabric where it belongs. Each system is designed to address the needs of individual applications. Track Guide system is well-suited to applications with squared or flat pillars or openings.

Track Guide System

The Oasis Track Guide system features an aluminum side track designed to allow smooth raising and lowering of the shade while keeping fabric in place with a specially designed hem bar. The hem bar is designed with a metal pin at each end which fits into the side track.

Insolroll Oasis 2800 sidetrack guide system keeps shade secured

  • Face mount or side mount
  • Vinyl rail guard for smooth operation
  • Matching plug buttons for face mount applications; not required for side mount
  • White, Bronze, Tan, and Black

Insolroll sidetrack face mount installation diagram

Insolroll Oasis 2800 sidetrack side mount installation diagram


Insolroll Oasis 2800 Cable guide system

Cable Guide System

Insolroll’s Oasis Cable Guide System features a nylon-coated stainless steel cable anchored in a deck mount or side mount bracket. Cable passes through a nylon guide pin in the specially designed hem bar. Cable guide system is excellent for applications with rounded or angled columns or masonry.

  • Cable Tension Lock
  • Choice of wall mount or deck mount bracket
  • Silver


Insolroll Oasis 2800 cable guide wall mount diagramInsolroll Oasis 2800 deck mount cable guide installation diagram
